Power Saving Copper Brazed Heat Exchanger Utilized In Energy Recovery Systems

High Pressure Brazed Plate Heat Exchanger Utilized In Energy Recovery Systems

Introduction :

ULTRA HIGH PRESSURE BRAZED Plate Heat Exchanger adopt double splint design , make its compact structure and more pressure-bearing . It can use in heat pump system with R722(CO₂) refrigerating fluid .

The heat exchanger is capable of handling extreme operating conditions, including high pressures and temperatures. It is commonly used in industrial processes such as oil and gas, chemical production, power generation, and refrigeration applications.

With its compact design and high heat transfer efficiency, the high-pressure brazed plate heat exchanger offers several advantages. It provides a large surface area for heat exchange within a small footprint, resulting in space savings and reduced installation costs.

the high-pressure brazed plate heat exchanger is a reliable and efficient solution for demanding applications where high-pressure operation and compact design are critical factors. Its advanced design and performance make it a preferred choice in various industries for efficient heat transfer and improved process efficiency.

The high-pressure brazed plate heat exchanger finds application in various industries and processes that require efficient heat transfer under high-pressure conditions

Applicable temperature : 200 ℃

Design Pressure : 14 Mpa

Test Pressure : 21 Mpa

Remark : splint material is Q235 , bolt for M16 , M20 , and available for suited lifting lug , footing , etc .
